◎ With high-rigidity frame design, they are welded using high-quality steel plates and undergo internal stress relief, so that the stability and reliability of the whole machine’s precision are enhanced.
◎ Consistent driving center and machine center ensure accurate and stable punching.
◎ Through hardening oxidation and precision grinding, parts such as crankshafts, gear sets, and connecting rods feature superior combination performance and tolerance.
◎ Equipped with highly sensitive and reliable clutch/brake, world-class duplex magnetic valves, and overload protection devices, it guarantees precision and safety for the operation and stopping of press rams.
◎ The machine features a reasonable structural design, facilitating automatic production, cost reduction, and efficiency improvement.
◎ Boasts advanced design concepts, low noise, low energy consumption, and energy-saving performance.

◎ Inverter
◎ Hydraulic Overload Protector
◎ Automatic Electric Grease Lubrication System
◎ Manual Slide Adjustment Device (60 Tons and Below)
◎ Electric Slide Adjustment Device (60 Tons and Below)
◎ Balance Device
◎ Anti-overload Safety Device
◎ Quick Die Change System
◎ Die Clamp Device
◎ Left/Right Feeding Device (60 Tons and Below)

◎ High-performance Wet Clutch & Brake
◎ Pneumatic Die Cushion Device
◎ Foot Switch
◎ Quick Die Change System (Die Lifter, Die Clamp & Die Arm Series)
◎ Slide Knock-out Device
◎ Anti-vibration Press Mount
◎ Photoelectronic Safety Device
◎ Feeder (Pneumatic, Mechanical & NC Types Available)
◎ Uncoiler
◎ Leveler
◎ Robotic Manipulator
◎ Die Light
◎ Touch Screen (Preset, Total Counter)
◎ PAC 100 Control System
◎ Human-Machine Interface (HMI) Control System
