◎ To ensure stable machine operation, dual balancers are installed for dynamic balance.
◎ Mould adjustment accuracy reaches 0.1mm, ensuring safe, fast and reliable operation.
◎ Key components such as crankshafts, gear sets and connecting rods are hardened, oxidized and precision-ground for superior performance and tolerance.
◎ Equipped with highly sensitive and reliable clutch/brake, world-class duplex solenoid valves and overload protection devices, guaranteeing precise and safe operation of the press ram.
◎ The machine features a rational structural design, facilitating automatic production, cost reduction and efficiency improvement.
◎ Boasts advanced design concepts, low noise, low energy consumption, and energy-saving performance.

◎ Inverter
◎ Hydraulic Overload Protector
◎ Automatic Electric Lubrication System
◎ Electric Slide Adjustment Device
◎ Electric Die Height Indicator
◎ Slide & Die Balance Device
◎ Rotary Cam Switch
◎ Misfeed Detection Device
◎ Power Outlet
◎ Crank Angle Indicator
◎ Electric Stroke Counter
◎ Air Source Connector
◎ Anti-overrun Safety Device
◎ Air Ejector
◎ Maintenance Tool Kit
◎ Operation Manual

◎ High-performance Wet Clutch & Brake
◎ Pneumatic Die Cushion Device
◎ Foot Switch
◎ Quick Die Change System (Die Lifter, Die Clamp & Die Transfer Arm)
◎ Slide Knock-out Device
◎ Anti-vibration Press Mount
◎ Photoelectric Safety Device
◎ Automatic Feeding System (Pneumatic, Mechanical & NC Types)
◎ Uncoiler
◎ Leveler
◎ Robotic Manipulator
◎ Die Light
◎ Touch Screen Control System (Preset & Total Counter)
◎ PAC 100 Control System
◎ Human-Machine Interface (HMI) Control System
